Escherichia coli
Escherichia coli Escherichia coli
Escherichia coli on blood agar is incubated for one day at 37° C.
Phase contrast microscope image of E. coli.
© Department of Veterinary Disease Biology 2011
Faculty of Health and Medical Sciences - University of Copenhagen
Denmark

Escherichia coli - Plate Count Agar
Escherichia coli Escherichia coli Escherichia coli
10-6 10-7 10-8
Click the images to enlarge

A dilution series of Escherichia coli has been prepared, seeded into the PCA and incubated aerobically at 25° C for three days. E. coli is a facultative anaerobic. Colonies on the surface is relatively large, off-white, while the colonies, which are inside the agar is lenticular. Colonies which lies between the Petri dish and the agar is transparent and gray.
© Department of Veterinary Disease Biology 2011
Faculty of Health and Medical Sciences - University of Copenhagen
Denmark

Escherichia coli - Plate Count Agar closeup
Escherichia coli
10-6
Colonies located on the surface are relatively large, off-white and round. Colonies which lies in the agar are whitish and lenticular. Colonies which lies between the agar and the petri dish are circular and greyish, transparent.
